Organ-on-chip Reveals Mechanism by which Pancreatic Cancer Drives Malignancy

Pancreatic cancer, which is slightly more common in men than in women, is one of the most lethal forms of cancer. On average, 95% of patients diagnosed with pancreatic cancer die from the disease. The disease, which accounts for about 3% of all cancers in the US and about 7% of all cancer deaths, is so lethal because during the early stages, when this cancer would be most treatable, there are generally no symptoms. And, as a results, it tends to be discovered at advanced stages when abdominal pain or jaundice may result. [1]

Following treatment, an average of only 9% of patients are alive five years after diagnosis.

According to the American Cancer Society, about 56,770 people (29,940 men and 26,830 women) will be diagnosed with pancreatic cancer this year and about 45,750 people (23,800 men and 21,950 women) are expected to of the disease.[1]

Poor outcome
Another reason for the poor outcomes is that pancreatic cancer cells are able to “escape” from tumors and enter the bloodstream very early in the disease. This means that, in many cases, the disease metastasizes before it the patient is diagnosed.

Lack of blood vessels
Paradoxically, pancreatic tumors appear to almost lack blood vessels altogether, which prevents cancer drugs from reaching and killing them and has puzzled scientists and clinicians trying to understand how the disease progresses.

A new study by researchers from Harvard’s Wyss Institute for Biologically Inspired Engineering, Boston University, and the University of Pennsylvania has finally shed light on this mystery.

Using both in vitro and in vivo models of pancreatic cancer and vasculature, it found that the tumor cells invade nearby blood vessels, destroy the endothelial cells that line them, and replace those cells with tumor-lined structures. This process seems to be driven by the interaction between the protein receptor ALK7 and the protein Activin in pancreatic cancer cells, pointing to a possible target for future treatments.

The research is published in Science Advances. [2]

“Our study really brings to light the importance of ‘rescuing’ the vasculature prior to treating pancreatic cancer, because this disease is actively destroying our only route for delivering drugs to metastatic tumors,” said co-first author Duc-Huy Nguyen, Ph.D., a postdoctoral associate at Weill Cornell Medicine who performed the research while a graduate student at the University of Pennsylvania.

“If we could prevent the cancer’s ablation of the surrounding endothelium by developing an inhibitor specific to the ALK7-Activin pathway, we could preserve the existing blood vessels and deliver drugs to patients to shrink down the tumor mass, which it is currently impossible to do,” Nguyen added.

Catching a killer
Studying the interactions between pancreatic cancer and blood vessels has historically been very difficult, as it would require multiple, invasive tissue biopsies from human cancer patients, and imaging the disease over time in the internal organs of living mouse models is technically very challenging.

The researchers took a different approach by using organs-on-chips: clear, flexible, plastic chips about the size of a USB stick containing microfluidic channels embedded in a collagen matrix that can be lined with living cells kept alive via a constant flow of nutrient-rich media.

To replicate a pancreatic cancer tumor, the team seeded one channel with mouse pancreatic cancer cells, and a neighboring channel with human endothelial cells. They observed that after about four days, the pancreatic cancer cells began to invade the collagen matrix toward the blood vessel channel, and eventually wrapped themselves around the channel, spread along its length, and finally invaded it. During the invasion process, the endothelial cells in direct contact with the cancer cells underwent apoptosis or programmed cell death, leading to a blood vessel channel that was composed exclusively of cancer cells.

The researchers saw the same pattern when using human pancreatic cancer cells in the organ-on-chip, and in living mouse models of pancreatic cancer, suggesting that this process may also occur in humans.

Identifying a new weapon
The researchers suspected that the mechanism by which pancreatic cancer cells ablate endothelial cells had something to do with the TGF-? signaling pathway, a cascade of molecular interactions that has been implicated in multiple types of cancers.

They introduced a TGF-? inhibitor into their organ-on-chip cancer model for seven days, and saw that the ablation of endothelial cells was significantly reduced. When pancreatic cancer cells were implanted into mice who were subsequently given the same inhibitor molecule, their tumors displayed a higher density of blood vessels, confirming that the inhibitor also reduced ablation in vivo.

To further hone in on the specific TGF-? receptor(s) driving the ablation process, the team created a co-culture device in which they grew pancreatic cells surrounded by endothelial cells so they could investigate exactly what was happening at the interface between the two cell types. They identified three candidate receptors – ALK4, ALK5, and ALK7 – and genetically deleted the gene coding for each receptor, first in the endothelial cells, then in the pancreatic cancer cells. They found that only by deleting ALK7 from the cancer cells could they significantly reduce ablation of endothelial cells and slowed cancer cell growth.

The ALK7 receptor has two known binding partners, the proteins Activin and Nodal, and when the researchers exposed in vitro cancer cells to compounds that inhibit each partner, only the Activin inhibitor reduced endothelial ablation, suggesting that the interaction between ALK7 and Activin is the major driver of pancreatic cancer’s growth and metastasis. This was further confirmed by knocking out ALK7 expression in cancer cells and then implanting them into mice, which resulted in slower-growing in vivo tumors with higher blood vessel density and fewer apoptotic endothelial cells.

“Not only has our study revealed a major insight into pancreatic cancer biology that could be used to drive the development of new treatments, our cancer-on-a-chip platform opens a new door to being able to more carefully study the interactions between blood vessels and other types of cancers, which could be extremely useful in teasing out these important but complex interactions,” said co-first author Esak (Isaac) Lee, Ph.D., who was a Postdoctoral Fellow at the Wyss Institute and Boston University when the research was carried out and is now an Assistant Professor at Cornell University.

Better understanding
The team is actively looking into developing their platform to further understand additional cellular interactions in cancer, including between cancer and immune cells, and between cancer and the perivascular cells that surround and support blood vessels.

“This study really demonstrates the power of using 3D and 2D organotypic models to replicate disease states in vitro and identify precise mechanisms, and their superiority over traditional in vitro and in vivo approaches,” said corresponding author Chris Chen, M.D., Ph.D., an Associate Faculty Member at the Wyss Institute who is also a Professor of Biomedical Engineering and Director of the Tissue Microfabrication Laboratory at Boston University.

“We are really just beginning to scratch the surface, and we’re excited to see what other kinds of insights we can uncover with this platform that could lead to new and better treatments,” Chen added.

“This elegant use of organ-on-a-chip technology by Chris Chen and his team provides an entirely new perspective as to why pancreatic cancer is such a malignant form of this disease, as well as potential new molecular targets that may lead to an entirely new class of anti-cancer therapeutics that act by preventing cancer cell colonization of blood vessels rather than targeting angiogenesis, immune cells, or the cancer cells themselves,” noted Donald Ingber, M.D., Ph.D., Wyss Institute Founding Director who is also the Judah Folkman Professor of Vascular Biology at HMS, the Vascular Biology Program at Boston Children’s Hospital, and Professor of Bioengineering at Harvard’s John A. Paulson School of Engineering and Applied Sciences (SEAS).

Reference
[1] Key Statistics for Pancreatic Cancer. How common is pancreatic cancer? American Cancer Society. Online. Last accesses August 26, 2019.
[2] Nguyen DT, Lee E, Alimperti S, Norgard RJ, Wong A, Lee JJ, Eyckmans J, Stanger BZ, Chen CS. A biomimetic pancreatic cancer on-chip reveals endothelial ablation via ALK7 signaling. Science Advances 28 Aug 2019:Vol. 5, no. 8, eaav6789. DOI: 10.1126/sciadv.aav6789 [Article]
